GYXTW 4B1 6B1 8B1 12B1 GYXTW53 Fiber Optic Cable

GYXTW has excellent mechanical and temperature performance;
The loose tube material itself has good hydrolysis resistance and high strength;
The tube is filled with special grease, providing crucial protection for the fiber;
It offers good compression resistance and flexibility;
The PE sheath provides excellent UV and radiation resistance;
Two parallel steel wires ensure the cable’s tensile strength;
The steel tape improves the cable’s moisture resistance.

What is GYXTW Fiber Optic Cable

GYXTW fiber optic cable is constructed using high-quality materials for durability and performance. The loose tube is made of hydrolysis-resistant material filled with a special water-blocking gel to protect the fibers. Two parallel steel wires are embedded for tensile strength, while a PE sheath provides UV and environmental protection. Additionally, the cable is reinforced with steel tape to improve moisture resistance.

GYXTW cables are known for their excellent mechanical and temperature resistance. The loose tube structure prevents damage from environmental factors, while the steel wires enhance tensile strength, making the cable ideal for long-distance installations. The combination of water-blocking gel and steel tape ensures superior moisture protection, giving the cable durability in harsh conditions.

Due to its robust design and features, GYXTW is commonly used in outdoor environments, especially for duct and aerial installations. Its tensile strength and moisture resistance make it suitable for applications where cables may face physical stress or exposure to water. This cable is widely used in telecom networks, offering reliable data transmission over long distances.

ተጨማሪ ያንብቡ

GYXTW Cable Specifications

ዝርዝሮች
ቴክኒካዊ መለኪያዎች
የእይታ ባህሪያት

የፋይበር ብዛት	2 – 24 Core
የፋይበር ዓይነት	G652D፣ G657A1፣ G657A2
የጃኬት ቁሳቁስ	PE
ቀለም	ጥቁር
የጥንካሬ አባል	steel wire
ርዝመት	1 ኪሜ ፣ 2 ኪሜ ፣ 3 ኪሜ ፣ 4 ኪሜ ፣ ሊበጅ የሚችል

Cable Type (Increased by 2 fibres)	Fibre Count	Cable Weight kg/km	Tensile Strength Long/Short Tern (N)	Crush Resistance Long/Short Term (N/100mm)	ማጠፍ ራዲየስ Static/Dynamic (mm)
GYXS/GYXTW-2~12Xn	2~12	82	600/1500	300/1000	10D/20D
GYXS/GYXTW-14-24Xn	14~24	127	600/1500
GYXS/GYXTW-2~12Xn	2~12	124	1000/3000
GYXS/GYXTW-14~24Xn	14~24	147	1000/3000

የፋይበር ዓይነት	አቴንሽን(+20℃)				የመተላለፊያ ይዘት		የቁጥር ቀዳዳ	Cable Cut-off Wavelengthλ
	@850nm	@1300nm	@1310nm	@1550nm	0850nm	o1300nm
ጂ.652			≤0.36dB/ኪሜ	022dB/km				≤1260 nm
ጂ.655			≤0.40dB/ኪሜ	≤0.23dB/ኪሜ				≤1450 nm
50/125μm	≤3.3dB/ኪሜ	≤1.2dB/ኪሜ		一	≥500ሜኸ · ኪሜ	≥500ሜኸ · ኪሜ	0.200 ± 0.015 NA
62.5/125μm	≤3.5dB/ኪሜ	≤1.2dB/ኪሜ			≥200ሜኸ · ኪሜ	≥500ሜኸ · ኪሜ	0.275 ± 0.015 ና

Benefits of GYXTW Optical Cable

Feature 1

High Tensile Strength

GYXTW features two parallel steel wires, providing excellent tensile strength, ideal for long-span aerial installations.

Feature 2

Superior Moisture Resistance

The steel tape and water-blocking gel inside the cable ensure high resistance to moisture, making it suitable for damp environments.

Feature 3

UV and Radiation Protection

The PE sheath offers strong UV and radiation protection, enhancing the cable’s durability in outdoor applications.

Applications of GYXTW Cables

GYXTW Aerial Optical Cable

GYXTW’s high tensile strength and moisture resistance make it ideal for aerial installations.

ጥያቄ አሁን ይላኩ።
GYXTW Duct Optical Cable

GYXTW’s compact design and moisture resistance make it suitable for duct installations.

ጥያቄ አሁን ይላኩ።
GYXTW Outdoor Optical Cable

GYXTW’s UV-resistant PE sheath and strong mechanical performance make it ideal for outdoor use.

ጥያቄ አሁን ይላኩ።

Download GYXTW Cable Catalog

GYXTW FIBER OPTIC CABLE CATALOG

ፒዲኤፍ

ካታሎጉን በፍጥነት ያውርዱ

ጊዜዎን ለመቆጠብ እባክዎ የእኛን ካታሎግ ያውርዱ

ሁሉንም ውርዶች ይመልከቱ

GYXTW Optical Cable Installation Precautions

When installing GYXTW optical cables, it’s important to avoid excessive bending to prevent damage to the fibers. Ensure that the cables are not exposed to moisture during installation and use appropriate protective measures in harsh environments. Pay attention to the tension applied when pulling the cable to prevent overstretching, and ensure it is properly supported in long spans, especially for aerial installations.

ጥያቄ አሁን ይላኩ።

ተጨማሪ ተዛማጅ ኬብሎች (4)

ADSS ገመድ

ጥያቄ አሁን ይላኩ።
ASU ገመድ

ጥያቄ አሁን ይላኩ።
የጂቲኤ ገመድ

ጥያቄ አሁን ይላኩ።
GYTS ገመድ

ጥያቄ አሁን ይላኩ።

What does GYXTW stand for?

GYXTW stands for a type of outdoor fiber optic cable where:

“GY” indicates it is an outdoor communication cable.
“X” refers to the central loose tube structure.
“T” represents the filling of the tube with water-blocking gel.
“W” indicates the presence of two parallel steel wires that provide additional tensile strength.

So, GYXTW is an outdoor fiber optic cable with a loose tube, water-blocking gel filling, and steel wires for enhanced strength.

Do you offer free samples for GYXTW optical cables?

Yes, we offer free samples of GYXTW optical cables for quality evaluation. You only need to cover the shipping costs.

What is the service life of GYXTW optical cable?

The service life of GYXTW optical cable is typically around 20 to 30 years, depending on environmental conditions and installation quality. Proper maintenance and handling can help extend its longevity.

What is the MOQ for purchasing GYXTW fiber optic cable?

The minimum order quantity (MOQ) for purchasing GYXTW fiber optic cable is usually set at 2 kilometers. This MOQ ensures convenient and cost-effective transportation while giving you a chance to evaluate the quality of the product firsthand.

What is the delivery time for purchasing GYXTW fiber optic cables?

The delivery time for GYXTW fiber optic cables largely depends on the order quantity. For smaller orders under 50 kilometers, the typical delivery time is around 10 days. However, for larger orders exceeding 300 kilometers, the delivery may take between 25 to 40 days to ensure proper production and quality control, guaranteeing that the cables meet high standards.
